Method Wheels

MR105 Beadlock

  • VENDOR: Method Wheels


  • PART #: MR10578516300B


    Your PRICE: Regular price $362.40



PRODUCT OVERVIEW:

Through years of race experience and rigorous FEA testing, Method had managed to bring an extremely durable yet light-weight beadlock to the hardcore enthusiast and racer. The Matte Black 105 Beadlock is TPMS compatible, has a decorative center cap, and a warranty on the finish. Included with the wheel is a matte black forged 6061 beadlock ring along with Grade 8 Zinc plated mounting hardware. Sizes offered are 17x8.5 and 17x9 with applications for numerous off road vehicles**. For specific Jeep JK and '04-up F150/Raptor applications, the center bores are machined to be hub-centric.

BRAKE FITMENT TECHNICAL DRAWING

WHEEL DIAMETER (IN) WHEEL WIDTH (IN) BOLT PATTERN BOLT HOLE  BOLT DIAMETER   OFFSET (MM) BACKSIDE SPACING (IN) ATV OFFSET B+F  HUB BORE (MM) MAX LOAD  (LBS)  COLOR/FINISH   PART NUMBER
17 8.5 5x5.5 5 5.5 0 4.75 N/A 108.0 3600 Matte Black MR10578555500B
17 8.5 6x5.5 6 5.5 0 4.75 N/A 108.0 3600 Machined with Matte Black Ring MR10578560300B
17 8.5 6x5.5 6 5.5 0 4.75 N/A 108.0 3600 Matte Black MR10578560500B
17 8.5 8x6.5 8 6.5 0 4.75 N/A 131.0 3600 Machined with Matte Black Ring MR10578580300B
17 8.5 8x6.5 8 6.5 0 4.75 N/A 131.0 3600 Matte Black MR10578580500B
17 9.0 5x4.5 5 4.5 -38 3.50 N/A 83.0 3600 Matte Black MR10579012538B
17 9.0 5x5 5 5 -38 3.50 N/A 71.5 3600 Machined with Matte Black Ring MR10579050338B
17 9.0 5x5 5 5 -38 3.50 N/A 71.5 3600 Matte Black MR10579050538B
17 9.0 6x5.5 6 5.5 -38 3.50 N/A 108.0 3600 Machined with Matte Black Ring MR10579060338B
17 9.0 6x5.5 6 5.5 -38 3.50 N/A 108.0 3600 Matte Black MR10579060538B
17 9.0 BLANK BLANK BLANK -38 3.50 N/A 71.5 3600 Matte Black MR10579000538B
20 9.0 6x135 6 135 -12 4.50 N/A 108.0 3500 Matte Black MR10529016512B
20 9.0 5x5 5 5 -12 4.50 N/A 108.0 3500 Matte Black MR10529050512B
20 9.0 6x5.5 6 5.5 -12 4.50 N/A 108.0 3500 Matte Black MR10529060512B
20 9.0 6x6.5 6 6.5 -12 4.50 N/A 108.0 3500 Raw Machined MR10529070312B
20 9.0 8x6.5 8 6.5 -12 4.50 N/A 130.0 3500 Matte Black MR10529080512B
20 9.0 BLANK BLANK BLANK -12 4.50 N/A 130.0 3500 Raw Machined MR10529000312B
