KC HiLites Gravity® LED G6 Optical Insert Pair Pack System

$245.00
SKU: 42134
Beam Pattern:

Beam Pattern

KC HiLites Gravity® LED G6 Optical Insert Pair Pack System

Spot

MCQUEEN

190 South McQueen Road
Suite 109
Gilbert AZ 85233
United States

+14806332929

STATE OF CALIFORNIA CONSUMER WARNING

Overview:
KC HiLiTES 6" Gravity LED Inserts allows you to upgrade existing Halogen 6" Daylighter and Pro-Sport lights. Features efficient CREE LEDs in a Wide-40 beam pattern. System includes (2) 6" 20w Gravity LED inserts.
Features:
  • 2 x 20W Gravity® LED G6 Optical Inserts
  • Aluminum Housing
  • Hard Coated Polycarbonate Lens
  • Wide-40 Beam Pattern
Light Performance (Per Light):
  • Raw Lumens: 2,300 lm
  • Lux @ 10 Meters: 390 lx
  • Candela: 39,000 cd
  • Beam Distance (Meters): 395m
SPECIFICATIONS (PER LIGHT):
  • Wattage: 20W
  • LED Source: CREE XPL HD LED
  • Amp Draw: 1.63A
  • Voltage: 9V-32V
  • IP Rating: IP68
  • Product Dimensions: W- 5.68" x H- 5.66" x D- 3.32"
Parts Included:

-(2) 20W 6" Gravity® LED G6 optical inserts

Gravity® EXTREME OUTPUT AND EFFICIENCY:

Gravity® G6 LED optical inserts deliver an incredible 390 lx @ 10m, in a super wide, wide-40 beam pattern. Our patented GRD (Gravity® Reflective Diode) system aims the LEDs into the precision reflectors, capturing all the light and projecting it forward.

AVAILABLE BEAM PATTERN AND ADVANTAGES:

Wide-40- Provides a wider and higher beam spread compared to our street legal fog beam patterns, while improving forward beam distance.

UPGRADE YOUR HALOGENS TO LED:

KC's Gravity® G6 LED optical inserts allow you to upgrade older KC 6" Halogen Daylighter and Pro-Sport housings, as well custom 6" openings with the latest LED technology.

STRENGTH & DURABILITY:

With an IP68 rated sealed aluminum reflector housing and durable polycarbonate lens to create a self contained LED light for maximum reliability and durability.

Specs:
  • Light Technology: LED
  • Location on Vehicle: A-Pillar / Ditch, Bumper, Overhead
  • Lumens: 2,300 lm
  • Beam Distance: 395 m
  • Total Wattage: 40W
  • Amp Draw: 3.3 a
  • Beam Pattern: Spot/Wide-40/Driving
  • DOT Compliant: No
  • SAE/ECE: No
  • Lens Color: Clear
  • Light Color: White
  • Product Dimensions: W - 5.68" x H - 5.66" x D - 3.32"
  • Finish: Black
  • Color: Black
  • In The Box: 2 x 20W Gravity® LED Wide-40 Beam G6 Optical Insert
  • IP rating: IP68
  • Prop 65: No
  • Size: 6"
