KC HiLites Gravity® LED G4 Universal Fog Light Single

$189.99
SKU: 1493

KC HiLites Gravity® LED G4 Universal Fog Light Single

MCQUEEN

190 South McQueen Road
Suite 109
Gilbert AZ 85233
United States

+14806332929

STATE OF CALIFORNIA CONSUMER WARNING

Overview:
KC HiLiTES 4" Gravity LED G4 Universal LED Fog Light feature bright CREE LEDs in a street legal fog beam pattern. Lightweight magnesium housing with optical reflectors, polycarbonate lens and universal adjustable bracket for easy mounting.

Harness & Wiring: Please keep in mind that the wiring harness is not included in the Single version of this light, but it is included in the Pair Pack / System version.

Features:
  • 10W 4" Gravity® LED Fog Lights
  • Lightweight Magnesium Housing for Maximum Heat Dissipation
  • Shatter Resistant Polycarbonate Lens
  • Fog Beam Pattern (SAE & ECE Street Legal)
LIGHT PERFORMANCE (PER LIGHT):
  • Raw Lumens: 866 lm
  • Compliance: SAE J583 & ECE-R19 Street Legal
  • Lux @ 10 Meters: 150 lx
  • Candela: 15,000 cd
  • Beam Distance (Meters): 245m
SPECIFICATIONS (PER LIGHT):
  • Wattage: 10W
  • LED Source: CREE LED
  • Color Temperature: 5000K
  • Amp Draw: .74A
  • Voltage: 9V-32V
  • IP Rating: IP68
  • Product Dimensions: W - 3.94" x H - 3.94" x D - 3.23"
Gravity®EXTREME OUTPUT AND EFFICIENCY:

4" Gravity® LED Fog Lights are powered by KC's patented Gravity® Reflective Diode (GRD) and optical reflectors to deliver an incredible 150 lx @10m using only .74A per light. KC's patented Gravity® Reflective Diode system aims LEDs into precision reflectors, capturing all light to project it forward.

AVAILABLE BEAM PATTERN AND ADVANTAGES:

Fog Beam- Provides a low, wide angle light pattern that increases short-range visibility. Ideal pattern for lighting pathways close to ground in low visibility conditions like dust, fog, snow and rain.

ADJUSTABLE MOUNTING FOR ACCURACY AND PRECISION:

KC's Innovative adjustable mount allows users to easily adjust the aiming of lights horizontally for an optimum and consistent beam angle.

STRENGTH & DURABILITY:

Constructed from an IP69 rated magnesium housing and polycarbonate lens creating a fully self contained LED light housing.

Specs:
  • Compliance DOT/SAE/ECE: SAE J583, ECE R19 (Fog)
  • Light Technology: LED
  • Location on Vehicle: Bumper, Fog Pocket
  • Lumens: 866 lm
  • Beam Distance: 245 m
  • Total Wattage: 10W
  • Voltage: 9V-32V
  • Amp Draw: 0.83 a
  • Beam Pattern: Fog
  • DOT Compliant: No
  • SAE/ECE: Yes
  • Lens Color: Clear
  • Light Color: White
  • Product Dimensions: W - 3.94" x H - 3.94" x D - 3.23"
  • Material: Magnesium Alloy
  • Finish: Black
  • Color: Black
  • In The Box: Gravity LED™ G4 SAE/ECE Fog Light, Universal Mounting Bracket, Hardware
  • IP rating: IP68
  • Prop 65: No
  • Size: 4"
